Atlas Apex 8 8,000 lb 4-Post Lift Car

The Atlas® APEX8 ALI Certified 4-Post Lift is the upgraded, safety-certified version of Atlas’s most popular hobbyist lift, the Atlas Garage PRO8000. Designed for homeowners, collectors, and restoration shops, the APEX8 is ideal for users who need to maximize garage space by safely stacking and storing multiple passenger vehicles.

Built for strength and long-term durability, the APEX8 is nearly 200 lbs heavier than comparable lifts, providing added stability and rigidity. It is ALI certified, offering an added layer of safety assurance and compliance with recognized automotive lift standards.

Unlike heavy-duty commercial lifts, the APEX8 is intended primarily for storage and light-duty use, making it ideal for enthusiasts rather than high-frequency repair shops. A included caster kit with polyurethane wheels allows the lift to be easily moved between bays or repositioned as needed, even outside the garage. The caster system can be installed or removed in minutes, giving the lift true portability.

The lift also features a double-lock safety system, single-point lock release, and lock ladder design for secure operation. With included ramps, wheel stops, and chocks, it is ready for both storage and light maintenance applications right out of the box.

Key Features

• Model: Atlas® APEX8
• Lift Type: ALI Certified 4-post storage lift
• Capacity: 8,000 lbs
• Intended Use: Homeowners, collectors, restoration shops (not for high-volume commercial repair use)
• Design: Free-standing / portable with caster kit
• Safety Certification: ALI Certified
• Lock System: Double-lock safety system with lock ladder design
• Lock Release: Single-point lock release
• Finish: Durable powder coat coating
• Included Accessories:
  • Steel approach ramps
  • Wheel stops
  • Two wheel chocks
  • Caster kit with polyurethane wheels
• Electrical Requirement: 110V, 30-amp breaker required
• Anchor Bolts: Optional (sold separately)
• Shipping Weight: 2,000 lbs

Specifications

• Capacity: 8,000 lb
• Max Lifting Height (runway top): 72 in (6 ft)
• Clearance Under Runways: 67 in (5′ 7″)
• Column Height: 86 5/8 in (7′ 2 5/8″)
• Overall Width (no motor/casters): 104 in (8′ 8″)
• Overall Width (with motor): 114 in (9′ 6″)
• Overall Length (no ramps): 186 1/2 in (15′ 6 1/2″)
• Overall Length (with ramps): 207 5/6 in (17′ 3 5/6″)
• Runway Length: 169 1/2 in (14′ 1 1/2″)
• Runway Width: 18 2/3 in
• Distance Between Runways: 38 in
• Distance Between Columns: 94 in (7′ 10″)
• Maximum Wheelbase: 154 in (12′ 9″)
• Drive-Thru Clearance: 80 1/4 in (6′ 8 1/4″)

Warranty

• Structural: 5 years
• Hydraulic: 2 years
